O-Rings cord
Category:
O-Rings/Seal Ring
- Product Description
-
- Commodity name: O-Rings cord
- Commodity ID: PC-0040
Rubber O-rings cord Circular Rubber Cords Buna-N Nitrile (NBR) 70 Duro Round O-ring Cord Metric O-ring Cord O-Ring Cord and Custom Extrusions Round Cords and Round Cord rings Quad Ring Cord Square O-Ring Cord Rectangular O-Ring Cord
Rubber O-ring cord is a continuous extruded rubber material wire used to manufacture O-rings and other seals.
91视频H污污 seals supply all standard AS568 and non-standard size O-ring cord, their diameter range from 1mm to 30mm, we can also make larger size sealing ring wire, we have a large inventory of NBR,FKM material rubber O-ring cord including DuPont's VITON O-ring cord.
We also make O-ring cord for square section, X / Quad Ring Cord and other cross section types. They come in a variety of materials (NBR, EPDM, FKM, silicone, etc.), sizes, hardness, and colors.
■.Rubber o-ring cord cross section type:1.Standard O-Ring Cord:cross-section is circular (O-shaped)
2.Quad Ring Cord:Its profile/cross-section is quad (X-shaped)
3.Square O-Ring Cord:Its profile/cross-section is square (quadrate-shaped)
4.Other special custom cross section shapes (according to customer requirements)
■.Properties of Rubber O-ring cord :
Tensile strength:500- 3000 PSI
Elongation at break %:100～300%
Density:1.0-2.5g/cm3Rubber material type: FKM,VITON,NBR,EPDM,Silicone,HNBR,etc.
Color:Black, brown, red, white etc.
■.Rubber O-ring cord Temperature Range:
Standard Low Temperature:-50℃(-58℉)
Standard High Temperature: -250℃(482℉)
※The temperature range is the reference value of the typical compounds, the value is different according to the material formulation,
■.Rubber O-ring cord Hardness range:50～ 90 Shore A (70 Shore A is the most common)
■.Rubber O-ring cord Cure system:Peroxide-Cured rubber o-ring cord possess greater resistance to high temperatures and a low compression set.
Sulfur-Cured o-ring cord include greater tear resistance and tensile strength.
■.Rubber O-ring cord dimensions：
CODE1: CS--Cross Section
CODE2: L--Total length
※For more information on rubber o-ring cord please contact 91视频H污污 seals
